New GORE® Acoustic Vent GAW331: Unsurpassed Sound After Immersion to 30 m
Gore takes the combination of immersion protection and acoustic performance to new levels! The new GAW331 maintains acoustic quality after immersion down to 30 m, for unsurpassed performance in wearables, smartwatches, action cameras, smartphones and other portable electronic devices.
Gore is introducing the next level of immersion protection and acoustic performance for wearables, smartwatches, action cameras, smartphones and other portable electronic devices.
The new GORE® Acoustic Vent GAW331 performs at levels not previously achieved:
It maintains excellent acoustic quality and reliable protection against liquid ingress, even after immersion in 30 meters of water, for 10 minutes!
Exceptional Acoustic Quality and Integrity is maintained, as GAW331:
- minimizes attenuation
- holds transmission loss below 2 dB at 1 kHz with a 3 mm vent diameter
Reliable Ingress Protection is assured, as GAW331 meets the most rigorous industry standards:
- ISO 22810 for watches: water-resistant after immersion in 30 m(3 bar) of water for 10 minutes
- IEC 60529 for smartphones: ingress protection ratings of IP67 and IP68
With the typical airflow of 285 ml/min/cm2 (dp = 70 mbar) the new GAW331 achieves the best balance of two competing needs: protecting the housing from immersion, and allowing the housing to
breathe, for high quality sound.
FOR INDUSTRIAL USE ONLY
Not for use in food, drug, cosmetic or medical device manufacturing, processing, or packaging operations.
