Higher Bandwidth Signals, Proven Robust Construction

GORE® Fiber Optic Cables balance strength, small size, less weight and high flexibility compared to alternatives. They deliver reliable signals at high bandwidths while meeting or exceeding stringent industry standards for wide temperatures, durability and optical performance.

Features & Benefits
Applications
Product Types
rugged fiber optic cable


Rugged construction of GORE Fiber Optic Cables, 1.8 mm Simplex

We construct GORE Fiber Optic Cables with rugged features that safeguard against complex routing, maintenance activities and harsh environmental conditions, including:

  • impact- and crush-resistant buffering systems
  • chemically inert and temperature-resistant materials
  • smaller, lighter, highly flexible cable diameters

For system architects and engineers, our rugged fiber optic cable solutions provide a handful of benefits that enhance system performance and longevity, like:

  • secure, high-bandwidth data and video transfer with low optical loss up to 100 Gb/s
  • proven resistance to high impact, crushing, abrasion, vibration, shock and more
  • proven to exceed new stringent EN4641-301, JN1177 and ARINC 802-3 durability requirements
  • easier, faster routing with more flexibility and tighter bend capability
  • valued weight and space savings in aircraft and armored vehicles
  • variety of single-mode & multi-mode core types from OM1 to OM5
  • compatible with a variety of high-speed connector systems and backshells
Fiber optics in military applications
Fiber optics in A380 civil avionics

GORE Fiber Optic Cables prove trustworthy in numerous defense aircraft, military land vehicles and commercial aircraft applications. We offer single-mode and multi-mode core types from OM1 to OM5 to meet many application needs.

Each version of our Simplex cables can be terminated with a variety of leading fiber optic connectors and backshells, like ARINC, MIL-STD-38999, and MIL-PRF-29504.

Applications 1.8 mm
Simplex
1.2 mm
Simplex
0.9 mm
Simplex (900 µm)
Avionics/Vetronics Digital Networks



Civil Aircraft Cabin Management Systems





Ethernet Backbone



Flight Management Systems



HD Camera/Video Systems



High Bandwidth in-LRU Data Paths





In-Flight Entertainment (IFE) Systems





Inside-the-Box Devices



Intercom/Radio Systems



In-Vehicle Networking





Laser Pigtails



Outside-the-Box Systems




(When packaged with GORE® Cable Protection Systems)

Radar Systems





Sensor/Processor Connectivity





Strain-Gauge Systems





Transceivers

Weather Radar Systems





1.8 mm Simplex

1.8mm simplex optical fibers

Our most popular award-winning version offers many benefits of a fiber optic cable. Built with a remarkable buffering system, our 1.8 mm Simplex is proven to resist high-weight impact, crushing, abrasion and kinking than other fiber optics for aerospace and military applications. It’s also proven to endure high-intensity vibration, mechanical shock and extreme temperatures, delivering higher bandwidth with low optical loss up to 100 Gb/s.


1.2 mm Simplex

1.2 mm Simplex

This fiber optic cable delivers stable optical performance with low loss for transferring high-bandwidth data and video up to 100 Gb/s on avionics and vetronics digital networks. Thanks to its small, flexible and durable construction, our 1.2 mm Simplex is easy to route in applications like inside-the-box devices.

900 micron (µm)

900 micron simplex optical fibers

Like our 1.8 mm Simplex, this optical fiber cable provides high-level crush resistance to protect the delicate fiber core, transmitting quality signals with minimal loss up to 100 Gb/s. This version also drastically reduces shrink back and shortens sample termination times. It’s an excellent choice for inside-the-box devices because it’s slender, flexible and easy to route. Our 900 micron can also be used for outside-the-box systems when packaged with GORE Cable Protection Systems.

GORE® Aerospace Fiber Optic Cables Impact Resistance Test

Impact Resistance Test

Gore tested the 1.8 mm Simplex according to ARINC 802-2 and BMS13-71 industry standards.

GORE® Fiber Optic Cables for Aerospace & Defense

GORE® Fiber Optic Cables for Aerospace & Defense

Watch the video to see how our Simplex optical fibers meet current and future high data rate requirements for military aircraft and combat vehicles, as well as civilian aircraft.

Technical Information

These values demonstrate the optical, mechanical and environmental performance of GORE Fiber Optic Cables for aerospace and defense.

Elec./Mech./ Environ. Property1.8 mm Simplex1.2 mm Simplexb0.9 mm Simplex
(900 µm)
Signal Transmission Speed Gb/sUp to 100Up to 100Up to 100
Max Optical Loss dB/km
 850 nm
 1300 nm
 1310 nm
4.0 / ≤ 5.0a
≤ 3.0a
3.0

≤ 1.5
3.0

1.0
Jacket MaterialPFAFEPPEEK
Jacket ColorViolet or YellowBlueTan
Core TypeSM or Multi-Mode, Graded IndexSM or Multi-Mode, Graded IndexSM or Multi-Mode, Graded Index
Coating TypeHigh-Temperature Acrylate
Buffering System

Expanded PTFE/Crush-Resistant Layer

OD: 900 µm (Nominal)

Expanded PTFE

Expanded PTFE/Crush-Resistant Layer

OD: 900 µm (Nominal)

Temperature Range °C-65 to +135-55 to +125c-65 to +135
DownloadsData SheetData SheetData Sheet

a. Based on Gore’s part numbers GSC-13-84943-07 and GSC-13-84943-17.
b. Based on Gore’s part number FON1307.
c. Other part numbers available with operating temperatures at +85°C and +200°C.

Complete the short form below for instant access to selected drawings with technical specifications from W. L. Gore & Associates.

Undergoing substantial qualification testing, GORE Fiber Optic Cables meet stringent industry standards and our customers’ requirements, including:

  • ABD0031 (AITM 2.0005); BSS7230; FAR Part 25, Appendix F, Part I: Flammability
  • ABD0031 (AITM 2.0005); BSS7230-F6; BSS7324-7.25; FAR Part 25, Appendix F, Part I: Flammability (FON1002, FON1003, FON1253, FON1307, FON1371)
  • ABD0031 (AITM 3.0008B); BSS7238; FAR Part 25, Appendix F, Part V: Smoke Density
  • ARINC 802-3; Performance Requirements (GSC-13-84639, GSC-13-84640, GSC-13-84943, GSC-13-85067-00)
  • ABD0031 (AITM 3.0005); BSS7239: Toxicity
  • EN3745-513; JN1177: Test Methods for Crush Resistance
  • MIL-STD-202, Method 103: Humidity (FON1002, FON1003, FON1253, FON1307, FON1371)
  • MIL-STD-810, Method 509: Salt Fog (FON1002, FON1003, FON1253, FON1307, FON1371)
  • MIL-STD-810, Method 510: Sand and Dust (FON1002, FON1003, FON1253, FON1307, FON1371)
  • STANAG 4754: NATO Generic Vehicle Architecture (NGVA) for Land System

Cable Type / ProtocolMode TypeCore/Cladding/CoatingJacket ColorGore Part Number
1.8 mm SimplexSingle Mode9/125/245YellowGSC-13-84689-04
Single Mode9/125/245VioletGSC-13-84689-07
OM1, Multi-Mode, Graded Index62.5/125/245YellowGSC-13-84640-04
OM1, Multi-Mode, Graded Index62.5/125/245VioletGSC-13-84640-07
OM2, Multi-Mode, Graded Index50/125/245YellowGSC-13-84639-04
OM2, Multi-Mode, Graded Index50/125/245VioletGSC-13-84639-07
OM3, Multi-Mode, Graded Index50/125/245YellowGSC-13-84943-04
OM3, Multi-Mode, Graded Index50/125/245VioletGSC-13-84943-07
OM3, Multi-Mode, Graded Index50/125/245VioletGSC-13-84943-17a
OM4, Multi-Mode, Graded Index50/125/245YellowGSC-13-85423-04
OM4, Multi-Mode, Graded Index50/125/245VioletGSC-13-85423-07
OM5, Multi-Mode, Graded Index50/125/245YellowGSC-13-85868-04
OM5, Multi-Mode, Graded Index50/125/245VioletGSC-13-85868-07
1.2 mm SimplexSingle Mode9/125/155BlueFON1002
OM1, Multi-Mode, Graded Index62.5/125/155BlueFON1003
Single Mode9/125/250BlueFON1253
OM2, Multi-Mode, Graded Index50/125/250BlueFON1307
OM1, Multi-Mode, Graded Index62.5/125/250BlueFON1371
0.9 mm Simplex
(900 µm)
OM1, Multi-Mode, Graded Index62.5/125/245TanGSC-13-85067-00
OM4, Multi-Mode, Graded Index50/125/245TanGSC-13-85424-00
Single Mode9/125/245TanGSC-13-85375-00
OM5, Multi-Mode, Graded Index50/125/245TanGSC-13-85869-00

a. Includes a JN1177 marking on the jacket material.
